8.1.4 Monitoring Display
b0.30 Running monitoring display
Setting range 0 ~ 70
Minimum unit 1
Factory default 0
b0.31 Stop monitoring display
Setting range 0 ~ 70
Minimum unit 1
Factory default 2
●
0: Output frequency
● 1: Output rotation speed
● 2: Set frequency
● 3: Set rotation speed
● 4: Output voltage
● 5: Output current
● 6: Output power
● 7: DC bus voltage
● 8: Analog input voltage (AIV)
● 9: Analog input current (AIC)
● 10: User-defined set velocity
● 11: User-defined output velocity
● 12: Digital input status
● 13: Digital output status
● 14: PID target engineering value
● 15: PID feedback engineering value
● 16: Module temperature
● 17: Firmware version 1
● 18: Firmware version 2
● 19: Firmware version 3
● 20: Actual carrier frequency
● 70: High resolution output current
The setting of parameter b0.30 decides which parameter of group d will be dis-
played in running monitoring mode.
● Example 1: [b0.30]=7
