Analog input channel gain
Code Name Setting range Min. unit Default Attri.
E0.10
Analog input voltage (AIV) channel gain
Kv
0.00 ~ 10.00 0.01 1.00 RUN/STOP
E0.12
Analog input current (AIC) channel gain
Kc
0.00 ~ 10.00 0.01 1.00 RUN/STOP
E0.11, E0.13 ~ E0.14 Reserved
Analog input filtering time
Code Name Setting range Min. unit Default Attri.
E0.15 Analog channel filtering time 0.000 ~ 2.000s 0.001s 0.100s RUN/STOP
E0.16 ~ E0.19 Reserved
Analog input curve configuration
Code Name Setting range Min. unit Default Attri.
E0.20 Analog setting curve selection 0 ~ 3 1 0 RUN/STOP
E0.21 Curve 1 min. reference 0.0 % ~ [E0.23] 0.1 % 0.0 % RUN/STOP
E0.22
Frequency corresponding to curve 1
min. reference
0.00 Hz ~ [b1.06] 0.01 Hz 0.00 Hz RUN/STOP
E0.23 Curve 1 max. reference [E0.21] ~ 100.0 % 0.1 % 100.0 % RUN/STOP
E0.24
Frequency corresponding to curve 1
max. reference
0.00 Hz ~ [b1.06] 0.01 Hz 50.00 Hz RUN/STOP
E0.25 Curve 2 min. reference 0.0 % ~ [E0.27] 0.1 % 0.0 % RUN/STOP
E0.26
Frequency corresponding to curve 2
min. reference
0.00 Hz ~ [b1.06] 0.01 Hz 0.00 Hz RUN/STOP
E0.27 Curve 2 max. reference [E0.25] ~ 100.0 % 0.1 % 100.0 % RUN/STOP
E0.28
Frequency corresponding to curve 2
max. reference
0.00 Hz ~ [b1.06] 0.01 Hz 50.00 Hz RUN/STOP
E0.29 ~ E0.39 Reserved
Setting range of E0.20:
0: AIC-reference characteristic curve 1, AIV-reference characteristic curve 1
1: AIC-reference characteristic curve 1, AIV-reference characteristic curve 2
2: AIC-reference characteristic curve 2, AIV-reference characteristic curve 1
3: AIC-reference characteristic curve 2, AIV-reference characteristic curve 2
