28: PSr-, problem with power supply on the main board
31: ESS-, soft start error
32: CE5-, internal problem on main board
33: UE-1, undervoltage during run
34: UH, frequency converter under temperature
35: FHE-, manufacturer parameter defect or mismatch to hardware
36: CE7-, 15 V power supply error
37: dir1, rotation direction error 1
38: dir2, rotation direction error 2
39: CE8-, communication problem on I/O board (No communication frames re-
ceived from I/O board)
40: CE0-, communication problem on main board (The communication frames
received from main board are checksum erroneous)
41: CE1-, communication problem on operating panel (The communication
frames received from removable panel are checksum erroneous)
42: CE2-, communication problem on main board (There is no communication
data from main board received in general)
43: CE6-, communication problem on removable board (There is no communica-
tion data from removable received in general)
44: CE9-, firmware version error
45: EEPr, EEPROM error on operating panel
47: OE-4, overvoltage during stop
50: t-Er, motor parameter identification error
51: SEr-, service data handling error (the main board does not receive the an-
swer after the retry limit)
System status at the latest error
Code
Name Setting range Min. unit Default Attri.
E4.30 Output frequency at latest error 0.00 Hz ~ [b1.05] 0.01 Hz 0.00 Hz read only
E4.31 Setting frequency at latest error 0.00 Hz ~ [b1.05] 0.01 Hz 0.00 Hz read only
E4.32 Output current at latest error 0.0 ~ 1,000.0 A 0.1 A 0.0 A read only
E4.33 Output voltage at latest error 0 ~ 1,000 V 1 V 0 V read only
E4.34 DC bus voltage at latest error 0 ~ 1,000 V 1 V 0 V read only
E4.35
Module temperature at latest
error
– 1 0 read only
EFC 3600 Bosch Rexroth AG
Appendix
DOK-RCON03-EFC-3600***-IT03-EN-P
239/259
