– 2: Acceleration time 2, set with parameter E2.00
– 3: Acceleration time 3, set with parameter E2.02
– 4: Acceleration time 4, set with parameter E2.04
● Display 0 (right most):
– 1: Deceleration time 1, set with parameter b1.21
– 2: Deceleration time 2, set with parameter E2.01
– 3: Deceleration time 3, set with parameter E2.03
– 4: Deceleration time 4, set with parameter E2.05
1. If the running time of a stage is set to be 0, simple PLC will
skip this stage.
2. PID control mode has higher priority compared with simple
PLC control. That is, if the PID control mode is active, then
simple PLC control will be disabled internally. So, the precon-
dition of running simple PLC is to disable PID control.
3. Simple PLC can be paused / prohibited by external terminals
and PLC cycle / phase completion can be signalized by digital
output. See details in parameter E0.01 ~ E0.05 and E1.00 ~
E1.02.
Rotation direction command source differs if running command source is differ-
ent, as shown in the table below:
Frequency
source
RUN command source Rotation direction Acc. / Dec. time
Multi-speed
By operating panel
parameters:
E2.35, E2.37, E2.39, E2.41,
E2.43, E2.45, E2.47, E2.49
parameters:
E2.35, E2.37,
E2.39, E2.41,
E2.43, E2.45,
E2.47, E2.49
By external terminals
External terminals, that is, 2-wire / 3-wire
control mode
By communication Set by communication
Simple PLC
By operating panel parameters:
E2.35, E2.37, E2.39, E2.41,
E2.43, E2.45, E2.47, E2.49
By external terminals
By communication
Tab. 8-4: Rotation direction and Acc. / Dec. time for multi-speed / simple PLC
