Fig. 8-49: Stall overcurrent prevention level_during acceleration
At constant speed
● When the output current exceeds the stall prevention level [E4.03], the fre-
quency converter starts deceleration with the defined deceleration time.
● When the output current drops below [E4.03], the frequency converter accel-
erates to the set frequency with the defined acceleration time.
Fig. 8-50: Stall overcurrent prevention level_at constant speed
E4.04 Low speed derating frequency
Setting range 0.10 ~ 300.00 Hz
Minimum unit 0.01 Hz
Factory default 25.00 Hz
E4.05 Zero speed load
Setting range 25.0 % ~ 100.0 %
Minimum unit 0.1 %
Factory default 25.0 %
