Minimum immunity requirements for PDSs intended for use in the second envi-
ronment
Port Phenomenon
Basic standard
for test
method
Level
Performance
(acceptance
criterion)
Enclosure port
ESD IEC 61000-4-2
4 kV CD or 8 kV AD
if CD impossible
B
Radio-frequency electromag-
netic field, amplitude modula-
ted
IEC 61000-4-3
80 ~ 1000 MHz 10 V/m
1.4 ~ 2.0 GHz 3 V/m
2.0 ~ 2.7 GHz 1 V/m
80 % AM (1 kHz)
A
Power ports
Fast transient-burst IEC 61000-4-4 2 kV/5 kHz B
Surge 1.2/50 μs, 8/20 μs IEC 61000-4-5
1 kV
a
, 2 kV
b
B
Conducted radio-frequency
common mode
IEC 61000-4-6
0.15 ~ 80 MHz 10 V
80 % AM (1 kHz)
A
Power interfaces
Fast transient-burst IEC 61000-4-4
2 kV/5 kHz
Capacitive clamp
B
Signal interfaces
Fast transient-burst IEC 61000-4-4
1 kV/5 kHz
Capacitive clamp
B
Conducted radio-frequency
common mode
IEC 61000-4-6
0.15 ~ 80 MHz 10 V
80 % AM (1 kHz)
A
Ports of process measurement control lines
Fast transient-burst IEC 61000-4-4
2 kV/5 kHz
Capacitive clamp
B
Conducted radio-frequency
common mode
IEC 61000-4-6
0.15 ~ 80 MHz 10 V
80 % AM (1 kHz)
A
Tab. 11-1: Minimum immunity requirements for PDSs intended for use in the second environ-
ment
