Electrical data
Using EMC filters in mains grounded via outer conductor.
When using EMC filters in mains grounded via outer conductor, use
an isolating transformer between mains and EMC filter.
Description
Symbol
Unit
E0006-A-240
E0010-A-240
E0020-A-240
E0025-A-240
E0008-A-480
E0020-A-480
Degree of protection ac-
cording to IEC 60529
– – IP 20
Listing according to UL
standard (UL)
– – UL 1283
Listing according to CSA
standard (UL)
– – C22.2 No.8
Mass (weight) m kg 0.26 0.42 0.86 0.87 0.58 0.75
Mains voltage three-phase
at TNS, TN-C, TT mains
U
LN
V 200...240 380…480
Mains voltage three-phase
at Corner- grounded-Delta
mains
U
LN
V Not allowed
Mains voltage three-phase
at IT mains
U
LN
V Not allowed
Tolerance U
LN
(UL)
% -10 %...+10 % -15 %...+10 %
Input frequency (UL)
f
LN
Hz 50...60
Nominal current
I
L_cont
A 6 10 20 25 8 20
Calculation of leakage cur-
rent
I
leak
mA < 0.5 < 0.5 < 3.5 < 3.5 13 3.1
Required wire size accord-
ing to IEC 60364-5-52; at
I
L_cont
A
LN
mm
2
2 2 3.5 5.3 4 5
Required wire size accord-
ing to UL 508 A (internal
wiring); at I
L_cont
(UL)
A
LN
AWG 14 14 12 10 10 10
Tab. 12-4: Electrical data
Bosch Rexroth AG
Accessories
EFC 3600
170/259
DOK-RCON03-EFC-3600***-IT03-EN-P
