REXROTH EFC 3600 - Page 186

EFC 3600
frequency converter
Brake
chopper
Brake resistor
Model
[kW]
Typecode
Type-
code
Qty. Typecode Parameter Qty.
0.4
1x200 V
0K40-1P2 Internal – 0060-N400R-D 400 Ω/60 W 1
0.75 0K75-1P2 Internal – 0100-N190R-D 190 Ω/100 W 1
1.5 1K50-1P2 Internal – 0200-N095R-D 95 Ω/200 W 1
2.2 2K20-1P2 Internal – 0300-N065R-D 65 Ω/300 W 1
0.4
3x400 V
0K40-3P4 Internal – 0060-N2K0R-D 2000 Ω/60 W 1
0.75 0K75-3P4 Internal – 0100-N1K0R-D 1000 Ω/100 W 1
1.5 1K50-3P4 Internal – 0200-N500R-D 500 Ω/200 W 1
2.2 2K20-3P4 Internal – 0300-N330R-D 330 Ω/300 W 1
4.0 4K00-3P4 Internal – 0500-N180R-D 180 Ω/500 W 1
Tab. 12-5: Brake resistor selection_braking ratio OT=10 %
□ means the typecode listed in the table; Qty. means Quantity.
EFC 3600
frequency converter
Brake
chopper
Brake resistor
Model
[kW]
Typecode
Type-
code
Qty. Typecode Parameter Qty.
0.4
1x200 V
0K40-1P2 Internal – 0100-N400R-D 400 Ω/100 W 1
0.75 0K75-1P2 Internal – 0200-N190R-D 190 Ω/200 W 1
1.5 1K50-1P2 Internal – 0400-N095R-D 95 Ω/400 W 1
2.2 2K20-1P2 Internal – 0500-N065R-D 65 Ω/500 W 1
0.4
3x400 V
0K40-3P4 Internal – 0100-N2K0R-D 2000 Ω/100 W 1
0.75 0K75-3P4 Internal – 0200-N1K0R-D 1000 Ω/200 W 1
1.5 1K50-3P4 Internal – 0400-N500R-D 500 Ω/400 W 1
2.2 2K20-3P4 Internal – 0500-N330R-D 330 Ω/500 W 1
4.0 4K00-3P4 Internal – 1K00-N180R-D 180 Ω/1000 W 1
Tab. 12-6: Brake resistor selection_braking ratio OT=20 %
Bosch Rexroth AG
Accessories
EFC 3600
172/259
DOK-RCON03-EFC-3600***-IT03-EN-P
