Error message after execution failure in PKW area
Error code Meaning Reason
1 Password locked User password is locked
2 Invalid command code Command codes (bit15 to 12 of ID) are not 0, 1 or 2.
3 Invalid parameter address
Invalid function group or index number of the func-
tion group, or insufficient access/rights
4 Invalid parameter value Data to write out of range
5 Forbid write in running mode Frequency converter is running
6 Parameter read-only Parameter are read-only, can not be written
7 Invalid operation
Function code does not support write or multiple
write via external computer
8 EEPROM access error EEPROM write operation is incomplete
Tab. 13-32: PKW area error codes
Example of parameter operation in PKW area
Example description
In applications, the master and the frequency converters communicate with
messages in PPO structure. Among the 5 PPOs stated in fig. 13-5 "PPO type" on
page 204, PPO 1, PPO 2 and PPO5 apply both PKW area and PZD area. In fol-
lowing examples, PKW area data frames are taken from complete PPO message
to describe its request and response data frames.
Example 1
Reading value of parameter b1.20 'Acceleration time 1'. 0x01 is the parameter
group, 0x14 is the index No. of the function code within the parameter group,
then request and response data frames in PKW area are shown in table below:
ID IND VALUE_high VALUE_low
Request data frame of PKW area 0x0001 0x0114 0x0000 0x0000
Response data frame of PKW area 0x0001 0x0114 0x0000 0x0032
Tab. 13-33: Example 1_request and response data frames of PKW area
