● After connecting the power supply terminals, the motor and the control ter-
minals, place the cover back before switching on the power. Take account of
the following instructions:
1. Ensure that the power supply can provide appropriate voltage and current.
Ensure that the rated current range is within that of the frequency convert-
er and power supply.
2. It is recommended to use 4-core cables to connect the motor. Cables are
connected to motor terminals PE-U-V-W.
3. If shielded cables are used, the shield layer of the motor cable should be
securely connected to
on the bottom right of the heat sink. The shielded
cables for the control signals should be connected to on control termi-
nal block.
It is recommended to use shielded cables in accordance with speci-
fied EMC classification.
EFC 3600 Bosch Rexroth AG
Mounting and Installation
DOK-RCON03-EFC-3600***-IT03-EN-P
25/259
