● 0: Basic parameters. In this mode, only parameters in group b (b0 and b1) are
visible.
● 1: Standard parameters. In this mode, parameters in group b and S (S0, S2
and S3) are visible.
● 2: Extended parameters. In this mode, parameters in group b, S and E (E0,
E1, E2, E3 and E4) are visible.
● 3: Advanced parameters. In this mode, parameters in group b, S, E and H
(H0) are visible.
● 4: Start-up mode. The parameters in this mode are not additional parameters,
but only quick links to the respective parameters. See the table below for de-
tails:
Function code Name
b0.21 Carrier frequency
b1.00 First frequency setting source
b1.02 First RUN command source
b1.05 Max. frequency
b1.06 Upper frequency
b1.07 Lower frequency
b1.04 Digital set frequency
b1.10 Direction control
b1.20 Acceleration time 1
b1.21 Deceleration time 1
b1.22 Acceleration / deceleration curve mode
b1.30 Starting mode
b1.40 Stopping mode
S0.00 V/F curve mode
S2.00 Rated motor frequency
S2.01 Rated motor rotation speed
S2.02 Rated motor power
S2.03 Rated motor voltage
S2.04 Rated motor current
Tab. 8-1: Parameters in start-up mode
●
Monitoring parameter group is always visible.
● User password protection will not affect the modification of
b0.02.
