b1.01 Digital set frequency saving
Setting range 0 ~ 3
Minimum unit 1
Factory default 0
Used to decide if the digital settings via ▲/▼ will be automatically saved at pow-
er off or in stop mode.
● 0: Not saved when powered off or stopped
● 1: Not saved when powered off; saved when stopped
● 2: Saved when powered off; not saved when stopped
●
3: Saved when powered off or stopped
Value changes set by b1.04 are always retained.
b1.02 The first RUN command source
Setting range 0 ~ 2
Minimum unit 1
Factory default 0
● 0: Inputting commands by operating panel
Using keys Run and Stop on the operating panel to run and stop the frequen-
cy converter.
● 1: Inputting commands by external terminals
Using external terminals to control run, stop, forward and reverse. For de-
tails, please refer to the description in group E0.
● 2: Inputting commands by communication
Running, stopping, forwarding or reversing of the frequency converter are
controlled by communication. See chapter 13 "Communication Protocols" on
page 184.
If [b1.02] = 1 or 2, the
Stop key on the operating panel can be ena-
bled with S3.35.
b1.03 Reserved
b1.04 Digital set frequency
Setting range 0.00 Hz ~ [b1.06]
Minimum unit 0.01 Hz
Factory default 50.00 Hz
When "The first frequency setting source" [b1.00]=1, the value of b1.04 is the
set frequency.
Bosch Rexroth AG
Parameter Settings
EFC 3600
54/259
DOK-RCON03-EFC-3600***-IT03-EN-P
