Fig. 8-13: Square curve
● 2: User-defined multipoint curve
Users can define a V/F curve with S0.01 ~ S0.06 for special loads of dewater-
ing machines, centrifuges, etc.
Fig. 8-14: User-defined multipoint curve
Excessive voltage at low-frequency may cause
the motor to overheat and be destroyed, and
the frequency converter may stall due to over-
current or activate overcurrent protection!
EFC 3600 Bosch Rexroth AG
Parameter Settings
DOK-RCON03-EFC-3600***-IT03-EN-P
69/259
