Fault parameters
Code Name Setting range Min. unit Default Attrib.
E4.11 Number of fault reset attempts 0...3 (0: Inactive for auto reset) 1 0 ◆
E4.12 Interval between reset attempts 2...60 s 1 10 ◆
E4.13 Last fault
0...26
1 0 ◎
E4.14
2
nd
last fault
1 0 ◎
E4.15
3
rd
last fault
1 0 ◎
E4.16 Delete fault record
0: Inactive; 1: Delete fault record
Note: The value is automatically set to 0 after
the operation.
1 0 ◆
Setting range of parameters E4.13...E4.15:
0: No fault record
1: Over current at constant speed (O.C.-1)
2: Over current during acceleration (O.C.-2)
3: Over current during deceleration (O.C.-3)
4: Over voltage at constant speed (O.E.-1)
5: Over voltage during acceleration (O.E.-2)
6: Over voltage during deceleration (O.E.-3)
7: Frequency converter over load (O.L.-1)
8: Motor over load (O.L.-2); 9: CPU read / write fault (R.E.)
10: Operating panel read / write fault (KEY-)
11: External device fault (E.-St)
12: Communication fault (R.S.)
13: Circuit disconnection (C.F.)
14: Pulse encoder speed detection fault (PULS)
15: Motor overheat (M.O.H.); 16: EMI fault (CPU-)
17: Short circuit (S.C.) ;18: Reserved
19: L1, L2, L3 input phase loss (IPH.L)
20: U, V, W output phase loss (OPH.L)
21: Frequency converter overheat (C.O.H.)
22: Parameter setting fault (PRSE)
23: Parameter auto-tuning fault (TUNE)
24: Frequency converter over load pre-warning 2 (O.L.-3)
25: Broken wire alarm (B.W.A)
26: Broken wire fault (B.W.F)
