9.2 General Technical Data
Input
Power supply voltage 3P 380...480 VAC (-15 % / +10 %) (TN-Net)
Power supply frequency 50...60 Hz (±5 %)
Output
Rated output voltage Corresponding to input voltage
Output frequency 0.00...400.00 Hz
Overload capability
150 % of rated current for 60 s
180 % of rated current for 10 s
Main
Functions
Control mode
V/F control (V/F)
Sensorless vector control (SVC)
Field oriented vector control (FOC)
Speed regulation range SVC: 100:1; FOC: 1000:1
Start-up torque
SVC: 150 % × rated torque at 0.50 Hz
FOC: 200 % × rated torque at 0.00 Hz
Frequency resolution
Analog setting: 1 / 2048 × maximum frequency
Digital setting: 0.01 Hz
Frequency setting accuracy Analog setting: 0.05 %; digital setting: 0.01 %
Frequency control accuracy
SVC: 0.5 % × maximum frequency
FOC: 0.05 % × maximum frequency
Multiple speed control Via integrated logic control or digital inputs
Status messages via multi-function output
signal
Outputs of Run, frequency level detection signal, frequen‐
cy arrival signal, faults, etc.
Automatic PWM frequency adaptation Load-dependent adaptation of PWM frequency
Customized
functions
Control commands
Set by operating panel, analog and digital inputs, serial
port
Frequency setting
Set by digital operating panel, analog voltage, analog cur‐
rent and serial port, which can be switched at any time
Auxiliary frequency setting
Flexible frequency fine tuning and frequency source com‐
bination (see parameter E0.09)
Analog outputs
Analog signal output, 0...20 mA or 0...10 V or -10...0 V, to
output physical values, such as output frequency
Operating panel
LCD display
Easy commissioning, display Run status, parameter val‐
ues and operating indications
LED indicator Showing set direction, Run status
Protection
Input phase failure protection, output phase failure protection, output short circuit protection, grounding
protection, over current protection, over voltage protection, under voltage protection, overload protec‐
tion, frequency converter overheat protection, motor overheat protection
Optional parts
Brake chopper, brake resistor, remote operation adapter, communication cable for cabinet control,
PROFIBUS adapter
