REXROTH Fv Series - Fv Figure

4.2.2 Fv Figure
Please refer to the above table to select four screws for Fv
mounting.
0K40...15K0
Fig. 4-3: 0K40...15K0 figure
18K5...37K0
Fig. 4-4: 18K5...37K0 figure
Bosch Rexroth AG DOK-RCON02-FV*********-IB08-EN-P38/259
Rexroth Frequency Converter Fv
Fv Mounting
