REXROTH Fv Series User Manual

10 Accessories
10.1 EMC Filter
10.1.1 The Function of EMC Filter
EMC filters are used to reduce radio interference and mains pollution.
Fv has an optional internal EMC filter. If higher EMC class is re‐
quired, please use an external EMC filter.
10.1.2 External EMC Filter Type
Fv model External EMC filter type code
0K40
FENF01.1B-A030-E0008-A-480-NNNN (E0008)
0K75
1K50
2K20
4K00
FENF01.1A-A075-E0025-A-480-NNNN (E0025)
5K50
7K50
11K0
FENF01.1A-A075-E0050-A-480-NNNN (E0050)
15K0
18K5
FENF01.1A-A075-E0066-A-480-NNNN (E0066)
22K0
30K0
FENF01.1A-A075-E0090-A-480-NNNN (E0090)
37K0
45K0
FENF01.1A-A075-E0120-A-480-NNNN (E0120)
55K0
75K0
FENF01.1A-A075-E0250-A-480-NNNN (E0250)
90K0
Tab. 10-1: External EMC filter type
The EMC filters listed above are recommended based on tests
with 10 m motor cables. If longer motor cables are needed,
please use appropriate EMC filters.
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 191/259
Rexroth Frequency Converter Fv
Accessories
