REXROTH Fv Series - Wiring Dimensions for Terminals

Wiring dimensions for terminals
Fv model Frame Terminal type
Wiring
dimensions
[AWG]
0K40
0K75
1K50
2K20
4K00
5K50
7K50
A
A
A
A
B
B
B
Main circuit terminals are shown as fig. 5-12 "Main circuit terminals illustra‐
tion_0K40...15K0" on page 54
10...20
Control circuit terminals are shown as
fig. 5-14 "Control circuit terminals_1" on page 57
fig. 5-15 "Control circuit terminals_2" on page 57
fig. 5-16 "Control circuit terminals_3" on page 57
16...26
11K0
15K0
C
Main circuit terminals are shown as fig. 5-12 "Main circuit terminals illustra‐
tion_0K40...15K0" on page 54
4...10
Control circuit terminals are shown as
fig. 5-14 "Control circuit terminals_1" on page 57
fig. 5-15 "Control circuit terminals_2" on page 57
fig. 5-16 "Control circuit terminals_3" on page 57
16...26
18K5
22K0
30K0
37K0
D
D
E
E
Main circuit terminals are shown as fig. 5-13 "Main circuit terminals illustra‐
tion_18K5 and above" on page 54
2...12
Control circuit terminals are shown as
fig. 5-14 "Control circuit terminals_1" on page 57
fig. 5-15 "Control circuit terminals_2" on page 57
fig. 5-16 "Control circuit terminals_3" on page 57
16...26
45K0
55K0
F
Main circuit terminals are shown as fig. 5-13 "Main circuit terminals illustra‐
tion_18K5 and above" on page 54
1 / 0... 8
Control circuit terminals are shown as
fig. 5-14 "Control circuit terminals_1" on page 57
fig. 5-15 "Control circuit terminals_2" on page 57
fig. 5-16 "Control circuit terminals_3" on page 57
16...26
75K0
90K0
G
Main circuit terminals are shown as fig. 5-13 "Main circuit terminals illustra‐
tion_18K5 and above" on page 54
4...4 / 0
Control circuit terminals are shown as
fig. 5-14 "Control circuit terminals_1" on page 57
fig. 5-15 "Control circuit terminals_2" on page 57
fig. 5-16 "Control circuit terminals_3" on page 57
16...26
Tab. 5-3: Wiring dimensions for terminals
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 53/259
Rexroth Frequency Converter Fv
Installation
