7.3.3 Category E - Extended Parameters
Group E0: Analog and digital inputs
Multi- function digital inputs
Code Name Setting range Min. unit Default Attrib.
E0.00 2-wire / 3-wire control mode
0: Forward / Stop, Reverse / Stop
1: Forward / Reverse, Run / Stop
2: 3-wire control 1
3: 3-wire control 2
1 0 ◆
E0.01
...
E0.08
Digital input X1
...
Digital input X8
0...29 1 0 ◆
Setting range of parameters E0.00...E0.08:
0: Inactive (allows multiple selection)
1: Multi-speed control 1
2: Multi-speed control 2
3: Multi-speed control 3
4: Multi-speed control 4
5: Acceleration / deceleration time 1
6: Acceleration / deceleration time 2
7: 3-wire control; 8: Freewheel to stop
9: Frequency increment UP
10: Frequency decrement DOWN
11: Set frequency to 0; 12: Reserved
13: Activate shutdown DC brake
14: Switch between operating panel and digital inputs control
15: Logic control deactivated
16: Logic control paused
17: Switch between speed and torque control
18: Switch between VR1 and +I analog reference
19: External fault N.O. contact input
20: External fault N.C. contact input
21: External Reset input
22: Activate communication control
23: Torque limit set by VR1 enabled
24: Torque limit set by VR2 enabled
25: Forward jogging; 26: Reverse jogging
27: Process PID deactivated
28: Speed limit set by VR1 enabled
29: Speed limit set by VR2 enabled
