Analog inputs
Code Name Setting range Min. unit Default Attrib.
E0.09 Source of analog frequency setting 0...7 1 0 ◆
E0.10 VR1 channel amplification factor k1 0.00...10.00 0.01 1.00 ◆
E0.11 VR2 channel amplification factor k2 0.00...10.00 0.01 1.00 ◆
E0.12 +I channel amplification factor k3 0.00...10.00 0.01 1.00 ◆
E0.13 Reference frequency curve 0...31 1 0 ◆
E0.14 Analog channel filter time 0.000...2.000 s 0.001 0.100 ◆
E0.15 Maximum input pulse frequency 1.0...50.0 kHz 0.1 20.0 ◆
E0.16 Curve 1 minimum reference 0.0 %...[E0.18] 0.1 0.0 ◆
E0.17 Frequency corresponding to curve 1 minimum reference 0.00...[b1.06] Hz 0.01 0.00 ◆
E0.18 Curve 1 maximum reference [E0.16]...100.0 % 0.1 100.0 ◆
E0.19 Frequency corresponding to curve 1 maximum reference 0.00...[b1.06] Hz 0.01 50.00 ◆
E0.20 Curve 2 minimum reference 0.0 %...[E0.22] 0.1 0.0 ◆
E0.21 Frequency corresponding to curve 2 minimum reference 0.00...[b1.06] Hz 0.01 0.00 ◆
E0.22 Curve 2 maximum reference [E0.20]...100.0 % 0.1 100.0 ◆
E0.23 Frequency corresponding to curve 2 maximum reference 0.00...[b1.06] Hz 0.01 50.00 ◆
E0.24
Analog reference forward / reverse dead zone control value
at -10...+10 V
0.0...30.0 % 0.1 0.0 ◆
Setting range of parameter E0.09:
0: k1 × VR1
1: k2 × VR2
2: k3 × (+I)
3: k1 × VR1 + k2 × VR2
4: k1 × VR1 + k3 × (+I)
5: k2 × VR2 + k3 × (+I)
6: k1 × VR1 (only valid for -10...+10 V forward / reverse control)
7: k4 × VR3
Setting range of parameter E0.13:
bit4: VR3 reference frequency characteristic curve
0: Curve 1; 1: Curve 2
bit3: Pulse reference frequency characteristic curve
0: Curve 1; 1: Curve 2
bit2: +I reference frequency characteristic curve
0: Curve 1; 1: Curve 2
bit1: VR2 reference frequency characteristic curve
0: Curve 1; 1: Curve 2
bit0: VR1 reference frequency characteristic curve
0: Curve 1; 1: Curve 2
Bosch Rexroth AG DOK-RCON02-FV*********-IB08-EN-P90/259
Rexroth Frequency Converter Fv
Parameter Settings
