7.3.4 Category H: Advanced Parameters
Group H0: Communication parameters
Code Name Setting range Min. unit Default Attrib.
H0.00 Communication protocol 0: Modbus; 1: PROFIBUS 1 0 ◆
H0.01 Baud rate
0: 1,200 bps; 1: 2,400 bps; 2: 4,800 bps
3: 9,600 bps; 4: 19,200 bps; 5: 38,400 bps
6: Reserved; 7: Data acquisition
1 3 ◆
H0.02 Data format
0: N, 8, 2
(1 start bit, 8 data bits, 2 stop bits, without check)
1: E, 8, 1
(1 start bit, 8 data bits, 1 stop bit, even check)
2: O, 8, 1
(1 start bit, 8 data bits, 1 stop bit, odd check)
1 0 ◆
H0.03 Local address
Modbus: 0...247 (0 represents broadcast address)
PROFIBUS: 0...126 (0 means deactivated)
1 0 ◆
H0.04 PZD4, PZD3 setting 0...255 1 0 ◆
H0.05 PZD6, PZD5 setting 0...255 1 0 ◆
H0.06 PZD8, PZD7 setting 0...255 1 0 ◆
H0.07 PZD10, PZD9 setting 0...255 1 0 ◆
H0.08
Communication discon‐
nection detection time
0.0...60.0 s (0.0: deactivated) 0.1 10.0 ◆
H0.09
Communication discon‐
nection action
0: Stop; 1: Keep running 1 0 ◆
H0.10 Reserved 0...65,535 1 0 ◆
Bosch Rexroth AG DOK-RCON02-FV*********-IB08-EN-P100/259
Rexroth Frequency Converter Fv
Parameter Settings
