7.2 Description of Attribute Symbols in Parameter Tables
The meaning of attribute symbols in the parameter tables are explained in the
table below.
Parameter attribute Description
◇ Parameter setting can be modified when the frequency converter is in run or stop mode.
◆ Parameter setting cannot be modified when the frequency converter is in run mode.
◎ Parameter setting is a calculated, measured or recorded value which cannot be modified.
Tab. 7-1: Parameter attributes and descriptions
Code: means function / parameter code, written in bx.xx, Sx.xx,
Ex.xx and Hx.xx.
Value of function / parameter code: written in [bx.xx], [Sx.xx],
[Ex.xx] and [Hx.xx].
Default: values that correspond to the factory default upon initiali‐
zation at 50 Hz.
Attrib.: means attribute.
