REXROTH Fv Series User Manual

● If parameter ‘Pulse output’ E1.16 is set to ‘0: Output frequency’, when
the output frequency reaches the maximum frequency F
max
, the corre‐
sponding set value of parameter ‘Maximum output pulse frequency’
E1.17 is output via output DO.
● If parameter ‘Pulse output’ E1.16 is set to ‘1: Output voltage’, when the
output voltage reaches 500 V, the corresponding set value of parameter
‘Maximum output pulse frequency’ E1.17 is output via output DO.
● If parameter ‘Pulse output’ E1.16 is set to ‘2: Output current’, when the
output current reaches the rated current, half of the corresponding set
value of parameter ‘Maximum output pulse frequency’ E1.17 is output
via output DO.
● If parameter ‘Pulse output’ E1.16 is set to ‘3: Encoder pulse', DO termi‐
nal outputs pulse with the same frequency of encoder pulse. The maxi‐
mum frequency of DO output is limited by [E1.17].
Group E2: Multi-Speed and logic control
E2.00
Acceleration time 2 Factory default 10.0
Setting range 0.1...3,600.0 s Minimum unit 0.1
E2.01
Deceleration time 2 Factory default 10.0
Setting range 0.1...3,600.0 s Minimum unit 0.1
E2.02
Acceleration time 3 Factory default 10.0
Setting range 0.1...3,600.0 s Minimum unit 0.1
E2.03
Deceleration time 3 Factory default 10.0
Setting range 0.1...3,600.0 s Minimum unit 0.1
E2.04
Acceleration time 4 Factory default 10.0
Setting range 0.1...3,600.0 s Minimum unit 0.1
E2.05
Deceleration time 4 Factory default 10.0
Setting range 0.1...3,600.0 s Minimum unit 0.1
● Acceleration / deceleration time 2, 3, 4 are defined the same meanings
as that of Parameter ‘Acceleration time 1’ b1.09 / ‘Deceleration time 1’
b1.10.
● Multifunction digital input Xi is used to select different acceleration / de‐
celeration time, see descriptions of parameters E0.01...E0.08.
E2.06
Multi-speed frequency 1 Factory default 0.00
Setting range [b1.07]...[b1.06] Hz Minimum unit 0.01
E2.07
Multi-speed frequency 2 Factory default 0.00
Setting range [b1.07]...[b1.06] Hz Minimum unit 0.01
E2.08
Multi-speed frequency 3 Factory default 0.00
Setting range [b1.07]...[b1.06] Hz Minimum unit 0.01
E2.09
Multi-speed frequency 4 Factory default 0.00
Setting range [b1.07]...[b1.06] Hz Minimum unit 0.01
E2.10
Multi-speed frequency 5 Factory default 0.00
Setting range [b1.07]...[b1.06] Hz Minimum unit 0.01
Bosch Rexroth AG DOK-RCON02-FV*********-IB08-EN-P144/259
Rexroth Frequency Converter Fv
Parameter Settings
