Page #145 background imageLoading...
Page #145 background image
If JP3 is set to 1-2, FM1 outputs voltage signals; if JP3 is set to be 2-3,
FM1 outputs current signals.
If JP4 is set to 1-2, FM2 outputs voltage signals; if JP4 is set to be 3-4,
FM2 outputs current signals.
Analog outputs are set with parameter ‘FM1 analog outputs’ E1.10, as
shown in table below.
[E1.10] Outputs Range
0
Output frequency / ro‐
tation speed
0...maximum output frequency, corresponds to
analog outputs set by E5.06...E5.08
1
Reference frequency /
rotation speed
0...maximum reference frequency, corresponds
to analog outputs set by E5.06...E5.08
2 Output current
0...2 times of rated current, corresponds to ana‐
log outputs set by E5.06...E5.08
3 Torque current
0 %...200 % of rated torque current, corresponds
to analog outputs set by E5.06...E5.08
4 Output voltage
0...1.2 times of rated voltage, corresponds to an‐
alog outputs set by E5.06...E5.08
5
Output frequency / ro‐
tation speed (including
direction)
0...maximum output frequency, corresponds to
analog outputs set by E5.06...E5.08 (0...10 V at
forwarding, -10...0 V at reversing)
6
Reference frequency /
rotation speed (includ‐
ing direction)
0...maximum reference frequency, corresponds
to analog outputs set by E5.06...E5.08 (0...10 V
at forwarding, -10...0 V at reversing)
7
Communication setting
(0x4003)
0...1,000 range of communication setting corre‐
sponds to analog outputs set by E5.06...E5.08
Tab. 7-15: Meanings of analog outputs
Parameter ‘FM1 gain setting’ E1.12 is used to set the gain of FM1.
E1.13
FM2 analog output Factory default 1
Setting range 0...4 Minimum unit 1
E1.14
Reserved Factory default 0
Setting range 0, 1 Minimum unit 1
E1.15
FM2 gain setting Factory default 1.00
Setting range 0.00...10.00 Minimum unit 0.01
The output range of analog output terminal FM2 can be set by parameters
E5.09...E5.12, the maximum output signal is 0...10 V or 4...20 mA. When
[E1.13]=5, the address of communication setting register is 0x4004. For other
information, please refer to the notes of FM1.
E1.16
Pulse output Factory default 0
Setting range 0...3 Minimum unit 1
E1.17
Maximum output pulse frequency Factory default 10.0
Setting range 1.0...50.0 kHz Minimum unit 0.1
DO pulse frequency output range: 0 kHz...[E1.17]
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 143/259
Rexroth Frequency Converter Fv
Parameter Settings
