Group E1: Digital and analog outputs
Multi-function digital outputs
Code Name Setting range Min. unit Default Attrib.
E1.00 Open collector output OUT1
0...14
1 1 ◆
E1.01 Open collector output OUT2 1 1 ◆
E1.02 Relay outputs Pa, Pb and Pc 1 1 ◆
E1.03 Frequency arrival detection width
0.0...20.0 %
(of maximum frequency [b1.05])
0.1 5.0 ◇
E1.04 Frequency detection level FDT1
0.0...100.0 %
(of maximum frequency [b1.05])
0.1 90.0 ◇
E1.05 Frequency detection level FDT1 width
0.0...100.0 %
(of maximum frequency [b1.05])
0.1 5.0 ◇
E1.06 Frequency detection level FDT2
0.0...100.0 %
(of maximum frequency [b1.05])
0.1 50.0 ◇
E1.07 Frequency detection level FDT2 width
0.0...100.0 %
(of maximum frequency [b1.05])
0.1 5.0 ◇
E1.08
Frequency converter over load pre-warn‐
ing 1 level setting
20.0...100.0 %
(of rated frequency converter current)
0.1 100.0 ◇
E1.09 Motor over load pre-warning level setting
100.0...250.0 %
(of rated motor current)
0.1 100.0 ◇
Setting range of parameters E1.00...E1.02:
0: Frequency converter is ready to run
1: Frequency converter is running
2: DC brake active
3: Frequency converter runs at zero speed
4. Frequency / speed arrival signal
5. Frequency level detection signal (FDT1)
6. Frequency level detection signal (FDT2)
7: Logic control phase completed
8: Under voltage stop
9: Frequency converter over load pre-warning 1
10: Motor over load pre-warning
11: Over torque
12: Frequency converter in fault
13: Fault auto reset signal output
14: Frequency converter over load pre-warning 2
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 91/259
Rexroth Frequency Converter Fv
Parameter Settings
