7.3.2 Category S: Standard Parameters
Group S0: V/F control
Code Name Setting range Min. unit Default Attrib.
S0.00 V/F mode
0: Linear mode
1: Square mode
2: User-defined multipoint mode
1 0 ◆
S0.01 V/F frequency 1 0.00...[S0.03] Hz 0.01 0.00 ◆
S0.02 V/F voltage 1 0.0...120.0 % (of ‘Rated motor voltage’ [S2.03]) 0.1 0.0 ◆
S0.03 V/F frequency 2 [S0.01]...[S0.05] Hz 0.01 0.00 ◆
S0.04 V/F voltage 2 0.0...120.0 % (of ‘Rated motor voltage’ [S2.03]) 0.1 0.0 ◆
S0.05 V/F frequency 3 [S0.03]...[b1.05] Hz 0.01 0.00 ◆
S0.06 V/F voltage 3 0.0...120.0 % (of ‘Rated motor voltage’ [S2.03]) 0.1 0.0 ◆
S0.07 Slip compensation 0.00...10.00 Hz 0.01 0.00 ◆
S0.08 Torque increase
0.0...20.0 %
(of rated frequency converter voltage)
● 0.0 %: Automatic increase
● 0.1 %...20.0 %: Manual increase
0.1 0.1 ◆
S0.09
Automatic voltage
stabilization
0: Not active
1: Always active
2: Not active during deceleration and braking
1 0 ◆
S0.10 Oscillation suppression gain
0.0...3.0
(0.0: deactivated)
0.1 0.3 ◇
Group S1: Vector control
Code Name Setting range Min. unit Default Attrib.
S1.00
Speed feedback proportional
gain
0.000...10.000 0.001 1.000 ◆
S1.01 Speed feedback integral time
0.000...10.000 s
(0.000 s means inactive)
0.001 1.000 ◆
S1.02 Torque limit 0.0...200.0 % (of rated motor current) 0.1 150.0 ◆
S1.03 Slip compensation gain 50.0...250.0 % 0.1 100.0 ◆
S1.04 Torque control selection
0: Inputs control
1: Always active
1 0 ◆
S1.05 Torque control reference
0: Input +I
1: Input VR1
2: Digital setting
3: Set by communication
1 0 ◆
S1.06 Torque digital setting 0.0...200.0 % 0.1 100.0 ◇
Bosch Rexroth AG DOK-RCON02-FV*********-IB08-EN-P86/259
Rexroth Frequency Converter Fv
