REXROTH Fv Series - Group S2: Motor and Encoder Parameters

Group S2: Motor and encoder parameters
Motor nameplate parameters
Code Name Setting range Min. unit Default Attrib.
S2.00 Rated motor frequency 8.00...400.00 Hz 0.01 50.00 ◆
S2.01 Rated motor rotation speed 1...24,000 rpm 1 1,440 ◆
S2.02 Rated motor power 0.4...1,000.0 kW 0.1
Depends
on model
◆
S2.03 Rated motor voltage 0...900 V 1 ◆
S2.04 Rated motor current 0.1...1,000.0 A 0.1 ◆
Motor parameters and adjustment
Code Name Setting range Min. unit Default Attrib.
S2.05 Stator resistance factor 0.00...50.00 % 0.01
Depends
on model
◆
S2.06 Rotator resistance factor 0.00...50.00 % 0.01 ◆
S2.07 Leakage inductance factor 0.00...50.00 % 0.01 ◆
S2.08 Mutual inductance factor 0.0...2,000.0 % 0.1 ◆
S2.09 No-load current 0.0...1,000.0 A 0.1 ◆
S2.10 Parameter auto-tuning
0: No action
1: Auto tuning with running motor
2: Auto tuning with static motor
Warning: Motor load has to be removed
before using auto-tuning function.
Note: The value is automatically set to 0
after auto-tuning.
1 0 ◆
S2.11 Reserved 0, 1 1 0 ◆
Encoder parameters
Code Name Setting range Min. unit Default Attrib.
S2.12 Pulses per revolution of pulse encoder 1...20,000 1 1,024 ◆
S2.13 Pulse encoder direction reverse
0: No reverse
1: Reverse
1 0 ◆
S2.14 Pulse encoder fault detection extent
0.0...1,000.0 rpm
(0.0 rpm: No break protection)
0.1 0.0 ◆
S2.15 Pulse encoder fault detection time 0.1...10.0 s 0.1 1.0 ◆
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 87/259
Rexroth Frequency Converter Fv
Parameter Settings
