Group E5: Extended parameters
Code Name Setting range Min. unit Default Attrib.
E5.00 VR3 channel amplification factor k4 0.00...10.00 0.01 1.00 ◆
E5.01 Pulse input filtering time 0...9 1 0 ◆
E5.02 Reserved 0, 1 1 0 ◆
E5.03 Reserved 0, 1 1 0 ◆
E5.04 Relay Ta, Tb and Tc output 0...14 1 12 ◆
E5.05 FM1 output lower limit 0.0 %...[E5.07] 0.1 0.0 ◇
E5.06 Output corresponding to [E5.05] 0.00...10.00 V 0.01 0.00 ◇
E5.07 FM1 output upper limit [E5.05]...100.0 % 0.1 100.0 ◇
E5.08 Output corresponding to [E5.07] 0.00...10.00 V 0.01 10.00 ◇
E5.09 FM2 output lower limit 0.0 %...[E5.11] 0.1 0.0 ◇
E5.10 Output corresponding to [E5.09] 0.00...10.00 V 0.01 0.00 ◇
E5.11 FM2 output upper limit [E5.09]...100.0 % 0.1 100.0 ◇
E5.12 Output corresponding to [E5.11] 0.00...10.00 V 0.01 10.00 ◇
E5.13 Delay time for frequency converter overload pre-warning 1 0.0...20.0 s 0.1 2.0 ◆
E5.14 Reserved 0, 1 1 0 ◆
E5.15 Reserved 0, 1 1 0 ◆
Setting range of parameter E5.04:
0: Frequency converter is ready to run
1: Frequency converter is running
2: DC brake active
3: Frequency converter runs at zero speed
4: Frequency / speed arrival signal
5: Frequency level detection signal FDT1
6: Frequency level detection signal FDT2
7: Logic control phase completed
8: Under voltage stop
9: Frequency converter overload pre-warning 1
10: Motor overload pre-warning
11: Over torque
12: Frequency converter in fault
13: Fault auto reset signal output
14: Frequency converter overload pre-warning 2
