9 Technical Data
9.1 Electrical Data
400 V series
Fv type code 0K40 0K75 1K50 2K20 4K00 5K50 7K50
Output power [kW] 0.4 0.75 1.5 2.2 4.0 5.5 7.5
Rated input current [A] 1.6 3.7 5.1 7.6 16.0 16.5 23.5
Rated output current [A] 1.3 2.5 4.0 5.5 10.0 13.0 17.0
Apparent power [kVA] 0.8 1.6 2.6 3.6 6.5 8.5 11.0
Fv type code 11K0 15K0 18K5 22K0 30K0 37K0 45K0
Output power [kW] 11.0 15.0 18.5 22.0 30.0 37.0 45.0
Rated input current [A] 36.0 46.0 48.0 53.0 73.0 88.0 104.0
Rated output current [A] 24.0 33.0 39.0 44.0 60.0 75.0 95.0
Apparent power [kVA] 15.0 21.0 24.0 30.0 40.0 50.0 62.0
Fv type code 55K0 75K0 90K0
Output power [kW] 55.0 75.0 90.0
Rated input current [A] 119.0 157.0 184.0
Rated output current [A] 110.0 152.0 176.0
Apparent power [kVA] 75.0 100.0 116.0
Tab. 9-1: Fv electrical data
The complete Fv type code is:
FVCA01.2-xxxx-3P4-MDA-LN-NNNN-01VRS
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 169/259
Rexroth Frequency Converter Fv
Technical Data
