9.3 Derating of Electrical Data
9.3.1 Derating and Ambient Temperature
Where installation conditions differ, the following performance data are re‐
duced in accordance with the diagram:
● Frequency converter continuous power output
● Frequency converter continuous current output
Use outside of the indicated installation conditions is not allowed,
even if the performance data are additionally reduced.
As the ambient temperature increases, the capacity utilization of the frequen‐
cy converter is reduced according to the figure below.
f
Ta
load factor
T
a_work
ambient temperature range for operation with nominal data
T
a_work_red
ambient temperature range for operation with reduced nominal
data
Fig. 9-1: Derating and ambient temperature
Bosch Rexroth AG DOK-RCON02-FV*********-IB08-EN-P172/259
Rexroth Frequency Converter Fv
Technical Data
