Environment
Power reduction / altitude
Up...1,000 m above sea level: none
1,000…4,000 m above sea level: 1 % / 100 m
Ambient temperature
-10...40 °C (without condensation and frost)
derating between 40...50 °C, see fig. 9-1 "Derating and
ambient temperature" on page 172
Relative humidity < 90 % RH (without condensation)
Shocking
< 5.9 m/s
2
(0.6 g)
Allowed pollution degree 2 (EN 50178)
Construction
Degrees of protection IP20 (control cabinet mounting)
Cooling type Enforced, air cooling
Mounting mode Hanging on the wall
Tab. 9-2: General technical data
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 171/259
Rexroth Frequency Converter Fv
Technical Data
