Group S3: Control parameters
Jog
Code Name Setting range Min. unit Default Attrib.
S3.00 Jog frequency 0.00...[b1.05] Hz 0.01 5.00 ◆
S3.01 Jog acceleration time 0.1...3,600.0 s 0.1 5.0 ◇
S3.02 Jog deceleration time 0.1...3,600.0 s 0.1 5.0 ◇
Skip frequency
Code Name Setting range Min. unit Default Attrib.
S3.03 Skip frequency 1 [b1.07]...[b1.06] Hz 0.01 0.00 ◆
S3.04 Skip frequency 2 [b1.07]...[b1.06] Hz 0.01 0.00 ◆
S3.05 Skip frequency 3 [b1.07]...[b1.06] Hz 0.01 0.00 ◆
S3.06 Skip frequency range 0.00...30.00 Hz 0.01 0.00 ◆
Restart after power off or power fault
Code Name Setting range Min. unit Default Attrib.
S3.07 Restart after power off or power fault
0: Deactivated
1: Activated
1 0 ◆
S3.08
Waiting time to restart after power off
or power fault
0.1...10.0 s 0.1 1.0 ◆
Other parameters in Group S3
Code Name Setting range Min. unit Default Attrib.
S3.09 Direction change dead time 0.0...3,600.0 s 0.1 4.0 ◆
S3.10 Droop control 0.00...10.00 Hz 0.01 0.00 ◆
S3.11 Setting velocity by UP / DOWN 0.01...100.00 Hz/s 0.01 0.08 ◇
S3.12 Brake chopper threshold 600...785 V 1 770 ◆
S3.13 Braking duty cycle 0...100 % 1 100 ◆
S3.14 Motor rotation direction
0: Standard motor direction
1: Reverse standard motor direction
2: Deactivate reverse motor rotation
1 0 ◆
S3.15 Stop key validity
0: Valid only for operating panel control
1: Valid for all control means
1 1 ◆
S3.16 Fan control
0: Temperature controlled
1: Always on
1 0 ◇
