4.2 Fv Dimensions and Figure
4.2.1 Fv Dimensions
Frame Fv model
Dimensions [mm]
Screw
size
Net weight
[kg]
B b T t H h h1 d D L1
A
0K40
0K75
1K50
125 75 122 1.5 275 300 315 5.5 127 5.5 M5
2.7
2K20 2.8
B
4K00
150 100 157 1.5 330 365 380 6.5 162 6.5 M6
4.8
5K50
7K50
4.9
C
11K0
175 100 199 2 398 432 448 6.5 204 6.5 M6
8.8
15K0 9.0
D
18K5
22K0
225 125 227 3.5 440 482 500 9 232 9 M8 16.5
E
30K0
37K0
250 150 251.5 3.5 525 567 585 9 256.5 9 M8 22.0
F
45K0
325 200 265 3.5 650 690 712.5 9 270 9 M8
37.0
55K0 39.0
G
75K0
450 300 302.5 4 700 754 779 11 307 11 M10
56.7
90K0 58.0
Tab. 4-1: Fv dimensions
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 37/259
Rexroth Frequency Converter Fv
Fv Mounting
