REXROTH Fv Series User Manual

Electrical data
Using EMC filters in mains grounded via outer conductor
When using EMC filters in mains grounded via outer conductor,
use an isolating transformer between mains and EMC filter.
Description
Symbol
Unit
E0008 E0025 E0050 E0066 E0090 E0120 E0250
Degree of protection
according to IEC60529
– – IP 20
Listing according to UL
standard (UL)
– – UL 1283
Listing according to CSA
standard (UL)
– – C22.2 No. 8
Mass (weight) m kg 0.6 1.1 1.8 2.7 4.2 4.9 5.0
Mains voltage three-phase
at TNS, TN-C, TT mains
U
LN
V 380…480
Mains voltage three-phase
at Corner- grounded-Delta
mains
U
LN
V Not allowed
Mains voltage three-phase
at IT mains
U
LN
V Not allowed
Tolerance U
LN
（UL）
– % +10 %...-15 %
Input frequency (UL)
f
LN
Hz 50...60
Nominal current
I
L_cont
A 8 25 50 66 90 120 250
Calculation of leakage cur‐
rent
I
leak
mA 13 15 15 16 18 18 <21
DC resistance typical value
R
typ
– 16 mΩ 5 mΩ 2 mΩ 1.5 mΩ 1.1 mΩ 0.9 mΩ 110 μΩ
Required wire size accord‐
ing to IEC 60364-5-52; at
I
L_cont
A
LN
mm
2
4 4 10 16 35 35
120
/2×70
Required wire size accord‐
ing to UL 508 A (internal
wiring); at I
L_cont
（UL）
A
LN
AWG 10 10 6 6 (2) 1 3/0 3/0 (2)
Tab. 10-3: Electrical data
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 195/259
Rexroth Frequency Converter Fv
Accessories
