12.3.5 Communication Parameter Configuration
Communication related parameter settings in Fv
Function code Function name Setting range of parameter
b1.00 Frequency setting mode 5: Set via communication
b1.02 Frequency converter control commands 2: Set control commands via communication
H0.00 Communication protocols selection 1: PROFIBUS protocols
H0.03 Local address 1...126
H0.04 PZD4, PZD3 setting 0...255
H0.05 PZD6, PZD5 setting 0...255
H0.06 PZD8, PZD7 setting 0...255
H0.07 PZD10, PZD9 setting 0...255
H0.08 Communication disconnection detection time 0.0...60.0s (0.0s: deactivated)
H0.09 Communication disconnection action
0: Stop
1: Continue running
Tab. 12-49: Fv PROFIBUS-DP communication parameters
If parameter [S3.15] = 1, when the frequency converter is stopped
by the Stop key on the operating panel, adapter is isolated from
communication software of the frequency converter. If communi‐
cation is to be re-established, Stop and Reset commands must be
sent to the frequency converter by the adapter.
Parameter configuration of master
Parameter configuration for related master may refer to instructions for the
master. The address configured for slave in the master should be consistent
with the parameter address configured for the slave. Communication baud
rate and PPO type is determined by the master.
GSD file
Users may log on the website of the company at www.boschrexroth.com/fv to
download electronic database document (RXFVDP01.gsd) and bit map docu‐
ment (RX_FV*.bmp) pack for fieldbus adapter. For specific operation and
PROFIBUS system configuration method, please refer to related system con‐
figuration documents.
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 247/259
Rexroth Frequency Converter Fv
