Acceleration / Deceleration time and modes
Code Name Setting range Min. unit Default Attrib.
b1.09 Acceleration time 1 0.1...3,600.0 s 0.1 10.0 ◇
b1.10 Deceleration time 1 0.1...3,600.0 s 0.1 10.0 ◇
b1.11 Acceleration / deceleration mode 0: Linear mode; 1: S-curve mode 1 0 ◆
b1.12 Time of S-curve rising section 1 0.0...40.0 % (of ‘Acceleration time 1’ [b1.09]) 0.1 20.0 ◆
b1.13 Time of S-curve rising section 3 0.0...40.0 % (of ‘Acceleration time 1’ [b1.09]) 0.1 20.0 ◆
b1.14 Time of S-curve falling section 4 0.0...40.0 % (of ‘Deceleration time 1’ [b1.10]) 0.1 20.0 ◆
b1.15 Time of S-curve falling section 6 0.0...40.0 % (of ‘Deceleration time 1’ [b1.10]) 0.1 20.0 ◆
Start or stop parameters
Code Name Setting range Min. unit Default Attrib.
b1.16 Start mode
0: Start mode 1
1: Start mode 2
2: Rotation speed capture mode
1 0 ◆
b1.17 Start frequency 0.00...15.00 Hz 0.01 0.50 ◆
b1.18 Start frequency hold time 0.0...10.0 s 0.1 0.0 ◆
b1.19 Stop mode
0: Decelerate to stop
1: Freewheel to stop
1 0 ◆
DC brake
Code Name Setting range Min. unit Default Attrib.
b1.20 Startup DC brake time
0.0...20.0 s
(0.0 s deactivates DC braking)
0.1 0.0 ◆
b1.21
Shutdown DC brake activation fre‐
quency
0.00...10.00 Hz 0.01 0.00 ◆
b1.22 Shutdown DC brake time
0.0...20.0 s
(0.0 s deactivates DC braking)
0.1 0.0 ◆
b1.23 DC brake current
0.0...150.0 %
(of rated frequency converter current)
0.1 0.0 ◆
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 85/259
Rexroth Frequency Converter Fv
Parameter Settings
