Analog outputs
Code Name Setting range Min. unit Default Attrib.
E1.10 FM1 analog output
0: Output frequency / rotation speed
1: Set frequency / rotation speed
2: Output current
3: Torque current
4: Output voltage
5: Output frequency / rotation speed (including direc‐
tion)
6: Set frequency / rotation speed (including direction)
7: Communication setting
1 0 ◇
E1.11 FM1 negative gain setting 0.00...10.00 0.01 1.00 ◇
E1.12 FM1 positive gain setting 0.00...10.00 0.01 1.00 ◇
E1.13 FM2 analog output
0: Output frequency / rotation speed
1: Set frequency / rotation speed
2: Output current
3: Torque current
4: Output voltage
5: Communication setting
1 1 ◇
E1.14 Reserved 0, 1 1 0 ◆
E1.15 FM2 gain setting 0.00...10.00 0.01 1.00 ◇
DO pulse outputs
Code Name Setting range Min. unit Default Attrib.
E1.16 Pulse outputs
0: Output frequency
1: Output voltage
2: Output current
3: Encoder pulse
1 0 ◇
E1.17
Maximum output
pulse frequency
1.0...50.0 kHz 0.1 10.0 ◇
