Noise immunity limit values
Place of
effect
Phenomenon
IEC
61000-
Standard
Conditions Coupling
Test values according
to standard EN 61800-3
Performance
level
Enclosure
port
ESD 4-2 – CD, AD 4 kV CD, 8 kV AD B
RF field 4-3 –
Via antenna
on EUT
10 V/m, 80...1,000 MHz
3 V/m, 1,400...2,000 MHz
1 V/m, 2,000...2,700 MHz
A
Power
port
Burst 4-4 –
mains connection
I<100 A: CDN
I≥100 A: clamp or
CN
2 kV / 5 kHz
(CN or CDN)
4 kV / 2.5 kHz (clamp)
B
Surge 4-5
only mains
connection;
I<63 A,
light load test
–
line-line 1 kV
line-earth 2 kV
B
Conducted radio-
frequency com‐
mon mode
4-6 Length>3 m clamp 10 V, 0.15...80 MHz A
Power
interface
Burst 4-4 Length>3 m clamp 2 kV / 5 kHz B
Signal
interface
Burst 4-4 Length>3 m clamp 1 kV / 5 kHz B
Conducted radio-
frequency com‐
mon mode
4-6 Length>3 m clamp or CDN 10 V, 0.15...80 MHz A
Ports of
process
Measure‐
ment con‐
trol lines
Burst 4-4 Length>3 m clamp 2 kV / 5 kHz B
Conducted radio-
frequency com‐
mon mode
4-6 length>3 m clamp or CDN 10 V, 0.15...80 MHz A
CD contact discharge
AD air discharge
CDN coupling and decoupling network
CN coupling network
Tab. 9-3: Noise immunity limit values
Evaluation criterion
Evaluation criterion Explanation (abbreviated form from EN 61800-3)
A Deviations within allowed range
B Automatic recovery after interference
C
Switched off without automatic recovery, device remains
undamaged
Tab. 9-4: Evaluation criterion
