ID IND VALUE_high VALUE_low
Request data frame of PKW area 0x8005 0x0600 0x0000 0x0BB8
Response data frame of PKW area 0x7005 0x0600 0x0000 0x0002
Tab. 12-32: Example 5_request and response data frames of PKW area
Example 6
If the user password is available, to modify the value of parameter 'Skip fre‐
quency range' S3.06. 0×05 is the function group, 0×06 is the index serial No.
within the group, and 0x0BB8 is the modified value, then the request and re‐
sponse data frames in PKW area are shown in table below:
ID IND VALUE_high VALUE_low
Request data frame of PKW area 0x2005 0x0600 0x0000 0x0BB8
Response data frame of PKW area 0x7005 0x0600 0x0000 0x0001
Tab. 12-33: Example 6_after user password modified_request and response data
frames of PKW area
Example 7
Forward run the frequency converter at 50.00 Hz（0x1388）, then modify the
value of parameter 'Skip frequency range' S3.06. 0×05 is the function group,
0×06 is the index serial No. within the group, and 0x0BB8 is the modified val‐
ue, then the request and response data frames in PKW area are shown in ta‐
ble below:
ID IND VALUE_high VALUE_low
Request data frame of PKW area 0x2005 0x0600 0x0000 0x0BB8
Response data frame of PKW area 0x7005 0x0600 0x0000 0x0005
Tab. 12-34: Example 7_request and response data frames of PKW area
Example 8
Modify the value of parameter 'Heat sink temperature' b0.12. 0x00 is the
function group, 0x0C is the index serial No. within the group, and 0x0001 is
the modified value, then the request and response data frames in PKW area
are shown in table below:
ID IND VALUE_high VALUE_low
Request data frame of PKW area 0x2000 0x0C00 0x0000 0x0001
Response data frame of PKW area 0x7000 0x0C00 0x0000 0x0006
Tab. 12-35: Example 8_request and response data frames of PKW area
Example 9
Modify the value of parameter 'LCD display in run mode' b0.08. 0x00 is the
function group, 0x08 is the index serial No. within the group, and 0x0BB8 is
the modified value, then the request and response data frames in PKW area
are shown in table below:
ID IND VALUE_high VALUE_low
Request data frame of PKW area 0x2000 0x0800 0x0000 0x0001
Response data frame of PKW area 0x7000 0x0800 0x0000 0x0007
Tab. 12-36: Example 9_request and response data frames of PKW area
Bosch Rexroth AG DOK-RCON02-FV*********-IB08-EN-P240/259
Rexroth Frequency Converter Fv
Communication Protocols
