REXROTH Fv Series User Manual

PZD1 PZD2 PZD3 PZD4 PZD5 PZD6
PPO request message
CW REF
0x0000 0x0000 0x0000 0x0000
0x0001 0x1388
PPO response message
SW ACT
0x0000 0x0206 0x02DD 0x0019
0x0002 0x1388
Tab. 12-43: Example 1 for PZD process data area_request and response messag‐
es of PPO
In this example, request and response data frame is the message
of frequency converter at stable operation. Actually, at the instant
start-up of the frequency converter, response data frame in PZD
area is “000× 0000 0001 0000 1369 0019” (× means rotation di‐
rection is not certain at the instant of activation).
Example 2
When the frequency converter forward runs at 50 Hz, to stop the frequency
converter as parameter settings, please refer to example 1.
PZD1 PZD2 PZD3 PZD4 PZD5 PZD6
PPO request message
CW REF
0x0000 0x0000 0x0000 0x0000
0x0008 0x1388
PPO response message
SW ACT
0x0000 0x0000 0x0049 0x0013
0x0000 0x0000
Tab. 12-44: Example 2 for PZD process data area_request and response messag‐
es of PPO
Example 3
To reverse start the frequency converter at 50 Hz, please refer to example 1
for parameter settings.
PZD1 PZD2 PZD3 PZD4 PZD5 PZD6
PPO request message
CW REF
0x0000 0x0000 0x0000 0x0000
0x0005 0x1388
PPO response message
SW ACT
0x0000 0x0206 0x02DA 0x001A
0x0003 0x1388
Tab. 12-45: Example 3 for PZD process data area_request and response messag‐
es of PPO
Example 4
When the frequency converter reverse runs at 50 Hz, to stop the frequency
converter as parameter settings, please refer to example 1.
PZD1 PZD2 PZD3 PZD4 PZD5 PZD6
PPO request message
CW REF
0x0000 0x0000 0x0000 0x0000
0x000C 0x1388
PPO response message
SW ACT
0x0000 0x0000 0x0040 0x0013
0x0001 0x0000
Tab. 12-46: Example 3 for PZD process data area_request and response messag‐
es of PPO
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 245/259
Rexroth Frequency Converter Fv
Communication Protocols
