Service
Program
Mode Tables
2603*
PTL Control: 154 mm/s (SSP)
Use this SP when an image problem occurs caused by the pick-off paws.
This SP is for the printing which target line speed is 154 mm/sec. Set the
PTL control (SP2603-001) to “1: ON” after installing the PTL. If the PTL
control is set to ON, the black line is come out due to exfoliation leave. Set
SP2911-002 (or 005, 008, 011) to “20” when using the PTL.
001
1st Side: OFF/ON [0 to 1 / 0 / 1]
Sets the PTL control setting for printing the first side of the paper.
002
1st Side: OFF Timing [-10 to 10 / 2 / 1]
Sets the PTL control time for printing the first side of the paper when
SP2602-001 is set to “1”.
003
2nd Side: OFF/ON [0 to 1 / 0 / 1]
Sets the PTL control setting for printing the second side of the paper.
004
2nd Side: OFF Timing [-10 to 10 / 2 / 1]
Sets the PTL control time for printing the second side of the paper when
SP2602-003 is set to “1”.
