System SP Tables-2
D129/D130 3-34 SM Appendix
2604*
PTL Control: 90 mm/s (SSP)
Use this SP when an image problem occurs caused by the pick-off paws.
This SP is for the printing which target line speed is 90 mm/sec. Set the PTL
control (SP2603-001) to “1: ON” after installing the PTL. If the PTL control is
set to ON, the black line is come out due to exfoliation leave. Set
SP2911-002 (or 005, 008, 011) to “20” when using the PTL.
001
1st Side: OFF/ON [0 to 1 / 0 / 1]
Sets the PTL control setting for printing the first side of the paper.
002
1st Side: OFF Timing [-10 to 10 / 2 / 1]
Sets the PTL control time for printing the first side of the paper when
SP2602-001 is set to “1”.
003
2nd Side: OFF/ON [0 to 1 / 0 / 1]
Sets the PTL control setting for printing the second side of the paper.
004
2nd Side: OFF Timing [-10 to 10 / 2 / 1]
Sets the PTL control time for printing the second side of the paper when
SP2602-003 is set to “1”.
2801*
TD Sensor Initial Setting Initialization
Performs the TD sensor initial setting and allows the service technician to
enter the lot number of the developer. (The lot number is embossed on the
edge of the developer package.) This SP mode controls the voltage applied
to the TD sensor to make the TD sensor output about 3.0 V. Press
"Execute" to start. After finishing this, the TD sensor output voltage is
displayed.
Use this mode only after installing the machine, changing the TD sensor, or
adding new developer.
