Ricoh Pro C5200s Operating Instructions Troubleshooting: Tcru/Oru

Letter Fold-out
L2
L1
Paper feed direction
CEZ534
Double Parallel
L2
L1
Paper feed direction
CEZ536
Gate Fold
L3
L2
L1
Paper feed direction
CEZ537
The mark indicates the leading edge (relative to the paper feed direction), and the mark indicates
the trailing edge.
<How to adjust the folding deviation>
This procedure is the same for L1, L2, and L3.
1. Open the front cover of the multi-folding unit.
5. Post-Processing Option Troubleshooting
100

Ricoh Pro C5200s Specifications

General

Print Technology	Laser
Max Paper Size	330.2 x 487.7 mm
Monthly Duty Cycle	300, 000 pages
Print Speed	65 ppm
Resolution	1200 x 4800 dpi
Paper Input Capacity	8, 250 sheets
Paper Weight	52 to 360 gsm
Duplex Printing	Standard
Network Connectivity	Ethernet 10Base-T/100Base-TX/1000Base-T
Supported Media Sizes	A3, A4, A5, B4, B5
Supported Media Types	Plain, Recycled, Coated, Envelope
Warm-up Time	Less than 5 minutes
