Ricoh Pro C5200s Operating Instructions Troubleshooting: Tcru/Oru

Cause:
The invert exit idle rollers in the drawer are soiled.
This may occur if:
• Sheets are delivered face down after one-sided printing
• Images are printed on a white or halftone yellow background
Solution:
Clean the invert exit idle rollers in the drawer.
1. Make sure that the system is turned off and the machine power cord is disconnected from
the power source.
2. Pull the drawer.
CWH001
3. Open the cover.
CWH414
3. Troubleshooting Image Quality Problems
24

Ricoh Pro C5200s Specifications

General

Print Technology	Laser
Max Paper Size	330.2 x 487.7 mm
Monthly Duty Cycle	300, 000 pages
Print Speed	65 ppm
Resolution	1200 x 4800 dpi
Paper Input Capacity	8, 250 sheets
Paper Weight	52 to 360 gsm
Duplex Printing	Standard
Network Connectivity	Ethernet 10Base-T/100Base-TX/1000Base-T
Supported Media Sizes	A3, A4, A5, B4, B5
Supported Media Types	Plain, Recycled, Coated, Envelope
Warm-up Time	Less than 5 minutes
