2. Check the present value. Is it lower than 50 A ?
Yes Carry out all of the following:
(1) Increase the value by 5 A in [Image Transfer Current: FC: K].
(2) Set [Paper Transfer Current: TE: FC] to "200%".
(3) Set [Paper Transfer Current: TE Length: FC] to "30 mm".
No No further improvement is likely. Contact your service representative.
3. Print the image. Is the problem resolved?
Yes Finished!
No Repeat Steps 1 to 3. If the problem persists even though you have increased the value to
50 A, contact your service representative.
<Printing in black and white>
1. In [Advanced Settings] for the custom paper in use, select [Image Transfer Current: BW].
2. Check the present value. Is it lower than 50 A?
Yes Carry out all of the following:
(1) Increase the value by 5 A in [Image Transfer Current: BW].
(2) Set [Paper Transfer Current: TE: BW] to "200%".
(3) Set [Paper Transfer Current: TE Length: BW] to "30 mm".
No No further improvement is likely. Contact your service representative.
3. Print the image. Is the problem resolved?
Yes Finished!
No Repeat Steps 1 to 3. If the problem persists even though you have increased the value to
50 A, contact your service representative.
3. Troubleshooting Image Quality Problems
34

Ricoh Pro C5200s Specifications

General

Print Technology	Laser
Max Paper Size	330.2 x 487.7 mm
Monthly Duty Cycle	300, 000 pages
Print Speed	65 ppm
Resolution	1200 x 4800 dpi
Paper Input Capacity	8, 250 sheets
Paper Weight	52 to 360 gsm
Duplex Printing	Standard
Network Connectivity	Ethernet 10Base-T/100Base-TX/1000Base-T
Supported Media Sizes	A3, A4, A5, B4, B5
Supported Media Types	Plain, Recycled, Coated, Envelope
Warm-up Time	Less than 5 minutes
