RKC INSTRUMENT PF900 User Manual

1. OUTLINE
IMR02L04-E3
1-4
 Output type availability
PID control with AT [: Usable : Not usable]
Output type
Details of output
Manipulated output
value 1 (MV1)
a
Manipulated output
value 2 (MV2)
a
Transmission output
Event output
Other
b
Output program
Output 1
(OUT1)
Relay contact 




Voltage pulse 




Voltage/Current 




Triac 




Open collector 




Output 2
(OUT2)
Relay contact 




Voltage pulse 




Voltage/Current 




Triac 




Open collector 




Output 3
(OUT3)
Voltage pulse 




Voltage/Current 




Open collector 




a
MV1 and MV2 can be used as Transmission output.
b
Other: Transmission output of Measured value (PV), Deviation value (DEV), Set value (SV) monitor and Segment time (percentage)
Heat/Cool PID control with AT [: Usable : Not usable]
Output type
Details of output
Manipulated output
value 1 (MV1)
[heat-side]
a
Manipulated output
value 2 (MV2)
[cool-side]
a
Transmission output
Event output
Other
b
Output program
Output 1
(OUT1)
Relay contact 




Voltage pulse 




Voltage/Current 




Triac 




Open collector 




Output 2
(OUT2)
Relay contact 




Voltage pulse 




Voltage/Current 




Triac 




Open collector 




Output 3
(OUT3)
Voltage pulse 




Voltage/Current 




Open collector 




a
MV1 and MV2 can be used as Transmission output.
b
Other: Transmission output of Measured value (PV), Deviation value (DEV), Set value (SV) monitor and Segment time (percentage)
Position proportioning PID control without FBR [: Usable : Not usable]
Output type
Details of output
Manipulated output
value 1 (MV1)
[open-side]
a
Manipulated output
value 2 (MV2)
[close-side]
a
Transmission output
Event output
Other
b
Output program
Output 1
(OUT1)
Relay contact 




Voltage pulse 




Voltage/Current 




Triac 




Open collector 




Output 2
(OUT2)
Relay contact 




Voltage pulse 




Voltage/Current 


c


Triac 




Open collector 




Output 3
(OUT3)
Voltage pulse 




Voltage/Current 




Open collector 




a
MV1 and MV2 can be used as Transmission output.
b
Other: Transmission output of Measured value (PV), Deviation value (DEV), Set value (SV) monitor and Segment time (percentage)
c
When Position proportioning PID control is selected, it is still possible to assign PV, SV, SV monitor or Transmission output of Segment
time (percentage) to OUT 2 while Manipulated output value 2 (MV2) [close-side] cannot be used.
