4. BASIC OPERATION
IMR02L04-E3 4-9
4.5 Parameter Description
Parameters are described by Mode type, Parameter list with Data range and Parameter switching diagram.
Reference page list
Mode type
Reference page
 Parameter list  Parameter switching
4.5.1 SV setting  monitor mode
SV setting mode
P. 4-9 P. 4-10, P. 4-11
Monitor mode
P. 4-12 P. 4-13
4.5.2 Operation mode
P. 4-14 P. 4-15
4.5.3 Parameter setting mode
Partial setting type *
P. 4-17 to P. 4-21 P. 4-22 to P. 4-25
Batch setting type *
P. 4-26 P. 4-27, P. 4-28
4.5.4 Setup setting mode
P. 4-29, P. 4-30 P. 4-31
4.5.5 Engineering mode
P. 4-32 to P. 4-43 P. 4-44 to P. 4-49
Initial level engineering mode Refer to the PF900/PF901 Instruction manual
on the CD-ROM.
* For Partial setting type and Batch setting type, refer to  Setting type for Program pattern (P. 4-16).
4.5.1 SV setting & monitor mode
Set the parameters such as the Segment level and Segment time in progress or switch the Execution pattern
selection screen, monitor screen of the Pattern remaining time, Manipulated output value (MV) etc.
 SV setting mode
Setting parameter varies with the operation mode (RESET, RUN, FIX, MAN) in the SV setting mode.
Refer to P. 4-10 and P. 4-11 to switch parameter setting display.
 Parameter list
Name Symbol Data range
Factory set
value
Reset mode (RESET)
Set value (SV) in Reset mode
SV
Setting limiter low to Setting limiter high 0
Execution pattern selection
PTN
1 to 99 (Within the maximum pattern number) 1
Program control mode (RUN)
Segment level
LEVEL
Setting limiter low to Setting limiter high 0
Segment time
TIME
From 0:00 to 500:00 (Hour: Minute), or
from 0:00 to 500:00 (Minute: Second)
0 hour
00 minute
Fixed set point control mode (FIX)
Set value (SV) in Fixed set point
control mode
SV
Setting limiter low to Setting limiter high 0
Continued on the next page.
PV/SV monitor
Setting parameters of each
Operation mode
Execution pattern selection
Setting of the manual manipulated
output value
(PV/SV monitor)
Press the PTN END key
(At RESET mode)
Returns to the PV/SV monitor
Press the 
key
Press the

key
Press the 
key
(Each operation mode)
Press the

key or the

key
(At MAN mode)
