4.5.3 Parameter setting mode
Parameters are classified into 12 setting blocks such as Program setting block, PID memory group setting
block and Event memory group setting block in the Parameter setting mode. Setting block may be switched
by using the
 key or the  key.
 Setting type for Program pattern
Partial setting or Batch setting is selectable for setting type of Program pattern in the Parameter setting mode.
To select the type, go to F80.03 (P.4-43) in the Engineering mode.
For parameter of the Engineering mode, refer to 4.5.5 Engineering mode (P. 4-32).
 Partial setting type (Factory set value)
Refer to P. 4-17 to 4-21 for Parameter list of the Partial setting type and P. 4-22 to 4-25 for
parameter switching.
 Batch setting type
Refer to P. 4-26 for Parameter list of the Batch setting type and P. 4-27 to 4-28 for parameter
switching.
* Settable only when Segment signal is specified.
Validates when specifying Segment signal function.
* Settable only when Segment signal is specified.
Validates when specifying Segment signal function.
Partial setting type consists of Program setting block
and Program memory group setting block. Setting
block varies based on the parameters.
Batch setting type consists of Program setting block
where all parameters related to Program pattern can be
set.
Segment level
Segment time
Parameters for pattern
Program setting block
Program memory group
setting block
Program setting block
Segment level
Segment time
Parameters for pattern
PID memory group number
Event memory group number
Wait memory group number
Segment signal *
PID memory group number
Event memory group number
Wait memory group number
Segment signal *
