IMR02L04-E1 8-1
8. SPECIFICATIONS
Measured input
Input type:
Low voltage group *
TC: K, J, T, S, R, E, B, N (JIS-C1602-1995)
PL II (NBS), W5Re/W26Re (ASTM-E988-96)
U, L (DIN43710-1985)
PR40-20 (ASTM-E17551-00)
RTD: Pt100 (JIS-C1604-1997)
JPt100 (JIS-C1604-1981 of Pt100)
3-wire system
Voltage: 0 to 10 mV DC, 10 to 10 mV DC,
0 to 100 mV DC, 100 to 100 mV DC,
0 to 1 V DC, 1 to 1 V DC
High voltage group *
Voltage: 0 to 5 V DC, 1 to 5 V DC, 0 to 10 V DC,
5 to 5 V DC, 10 to 10 V DC
Current group *
Current: 4 to 20 mA DC, 0 to 20 mA DC
*
Universal input
(
Use the input select switch to change input group.)
Sampling cycle:
100 ms (50 ms or 250 ms is selectable)
Influence of external resistance:
Approx. 0.2 V/
(Converted depending on TC types)
Influence of input lead:
Approx. 0.01 of span (Only RTD input)
10 or less per wire
(When the value is 10 Ω or more, measuring range may be
limited.)
Input impedance:
Voltage (low) input: Approx. 1 M or more
Voltage (high) input: Approx. 1 M or more
Current input: Approx. 50
Measured current:
Approx. 0.25 mA (Only RTD input)
Allowable input voltage:
Within 5 V
(High voltage group: Within 12 V)
Square root extraction (Voltage/Current inputs):
Calculation method:
Measured value
= (
Input value
)
PV ratio
+
PV bias
PV low input cut-off:
0.00 to 25.00 % of Input span
Current transformer (CT) input [optional]
Number of inputs: 2 points
Input range: CTL-6-P-N: 0.0 to 30.0 A
CTL-12-S56-10L-N: 0.0 to 100.0 A
Feedback resistance (FBR) input [optional]
Number of input: 1 point
Permissible resistance range:
100 to 10 k (Standard: 135 )
Input range: 0.0 to 100.0
(
for adjustment span of open and close
)
Digital input
Number of inputs: Up to 11 points
(6 points: DI1 to DI6 [optional], 5 points: DI7 to DI11 [standard])
Input method: Dry contact input
Open state: 10 k or more
Close state: 1 k or less
Contact current: 5 mA or less
Voltage at open: Approx. 5 V DC
Capture judgment time:
200 ms max. + 1 sampling cycle
Output
Number of outputs:
Up to 15 points (OUT1 to OUT3, DO1 to DO12)
OUT3 and DO5 to DO12 is optional
Output type:
Relay contact output (OUT1 and OUT2)
Contact type: 1a contact
Contact rating (Resistive load):
250 V AC 3 A, 30 V DC 1 A
Relay contact output (DO1 to DO4)
Contact type: 1a contact
Contact rating (Resistive load):
250 V AC 1 A, 30 V DC 1 A
Voltage pulse output (OUT1 to OUT3)
Output voltage: 0/12 V DC (Rating)
ON voltage:
11 V or more, 13 V or less
OFF voltage: 0.2 V or less
Allowable load resistance:
600 or more (20 mA or less)
OUT1: 300 Ω or more when not using OUT2.
(40 mA or less)
Current output (OUT1 to OUT3)
Output current (Rating):
4 to 20 mA DC, 0 to 20 mA DC
Allowable load resistance: 600 or less
Voltage output (OUT1 to OUT3)
Output voltage (Rating):
0 to 1 V DC *, 0 to 5 V DC, 1 to 5 V DC,
0 to 10 V DC
* Available for OUT3
Allowable load resistance: 1 k or more
Triac output (OUT1 and OUT2)
Output method: AC output (Zero-cross method)
Allowable load current:
0.5 A (Ambient temperature 40 C or less)
(Derating: 0.02A/C when ambient is 40 C
or more.)
Load voltage: 75 to 250 V AC
Minimum load current: 30 mA
ON voltage: 1.6 V or less (
at maximum load current
)
Open collector output (OUT1 to OUT3)
Allowable load current: 100 mA
Load voltage: 30 V DC or less
ON voltage: 2 V or less (at maximum load current)
Leakage current at OFF: 0.1 mA or less
To Next Page
