8. SPECIFICATIONS
IMR02L04-E1
8-2
Open collector output (DO5 to DO12)
Output method: Sink type
Use same common terminal for DO5
to DO8 and DO9 to DO12.
Allowable load current: 100 mA
Load voltage: 30 V DC or less
ON voltage: 2 V or less (
at maximum load current
)
Leakage current at OFF: 0.1 mA or less
Performance
(at the ambient temperature 23 ±2 C)
Input accuracy:
Measured input:
Input type Input range Accuracy
K, J, T, PLII,
E, U, L
(Accuracy is
not guaranteed
for less than
−100 C)
Less than 100 C 1.0 C
100C or more, less than 500 C 0.5 C
500 C or more
(0.1 of
Reading)
S, R, N,
W5Re/W26Re
(Accuracy is
not guaranteed
for less than
400 °C for
Input type S, R,
and
W5Re/W26Re.
)
Less than 0 C
2.0 C
0C or more, less than 1000 C
1.0 C
1000 C or more
(0.1 of
Reading)
B
(Accuracy is
not guaranteed
for less than
400 °C)
Less than 400 C 70 C
400C or more, less than 1000 C 1.4 C
1000 C or more
(0.1 of
Reading)
PR40-20
Less than 400 C 20 C
400C or more, less than 1000 C 10 C
1000 C or more
(0.1 of
Reading)
Pt100, JPt100
Less than 200 C 0.2 C
200 C or more
(0.1 of
Reading)
Voltage
0.1 of Input span
Current
Cold-junction temperature compensation error:
Within 1.0 C
Within 1.5 C (Between 10 to
55 C)
Current transformer (CT) input:
5 of Reading or 2 A (whichever is larger)
Feedback resistance (FBR) input:
0.5 1 digit of Input span (for adjustment span of
open and close)
Output accuracy:
Current output: 0.1 of Output span
Output resolution: Approx. 1/10000
Voltage output: 0.1 of Output span
Output resolution: Approx. 1/10000
Control
Control method:
a) Brilliant II PID control
b) Brilliant II Heat/Cool PID control
c) Brilliant II Position proportioning PID control
d) Manual control
Selectable from a) to d)
Event function
Number of events: Up to 4 points (Event 1 to 4)
Event action:
Deviation high, Deviation low,
Deviation high/low (High/Low common setting),
Deviation high/low (High/Low individual setting),
Band (High/Low common setting), Band (High/Low
individual setting), Process high, Process low,
SV high, SV low, MV1 high [heat-side]
*,
MV1 low [heat-side]
*, MV2 high [cool-side],
MV2 low [cool-side]
* Position proportioning PID control: Feedback resistance (FBR)
input value
Control loop break alarm (LBA)
Setting range:
Control loop break alarm (LBA) time:
0 to 7200 seconds (0: LBA function OFF)
LBA deadband (LBD):
0 to Input span
Additional function: LBA interlock
Heater break alarm (HBA) [for time
proportional-control output] (optional)
Number of HBA:
Up to 2 points (1 point for three-phase)
Setting range:
0.0 to 100.0 A (0.0: HBA function OFF)
Current value monitor is available regardless of
whether HBA is OFF. It is not possible to detect the
value if the ON time or OFF time of control output
is within:
160 ms (with CT sampling cycle of 200 ms).
140 ms (with CT sampling cycle of 100 ms).
220 ms (with CT sampling cycle of 500 ms).
Additional function:
Number of HBA delay times,
HBA interlock
Transmission output [optional]
Number of output: 1 point (Use the OUT1 to OUT3)
Output contents:
Measured value (PV), Set value (SV) monitor,
Deviation value, Output program value *,
Segment time (percentage basis)
* For OUT1, only Output program value 1 is available.
To Next Page
